Add Lua scripting capabilities to C# environments such as Unity,.Net, and Mono

xLua is a framework for adding Lua scripting to C# environments such as Unity,.NET, and Mono.

xLua adds Lua scripting capabilities to C# environments such as Unity,.NET, and Mono. With xLua, these Lua codes can be easily intercalled with C#.

class=”pgc-h-arrow-right” data-track=”5″>

overall

• • The core code does not depend on the generated code, and the generated directory can be deleted at any time
  • lua functions are mapped to c# delegate, lua table is mapped to interface, and there is no C# gc alloc overhead at the interface level
  • All primitive value types, all enumerations, fields are value type struct, passed between Lua and C# No C# gc alloc
  • LuaTable, LuaFunction provides GC-free access interface
  • Generate optimal code through static analysis during code generation
  • Support pointer passing between C# and Lua
  • Add Lua third-party extensions

without changing the code

• Generate engine to provide interface for secondary development

C# call Lua

• • Call Lua function
  • Call Lua function as delegate
  • Call lua function with LuaFunction
  • Access Lua’s table
  • LuaTable generalized Get/Set interface, call without gc, can specify the type of Key, Value
  • access

with interface annotated with CSharpCallLua

• Copy the value to struct, class

toolchain

• Lua Profiler
• can be sorted according to the total call duration, average call duration and number of calls
• shows the name of the lua function and the name and line number of the file it is located in
• If a C# function, it will show that this is a C# function
• Support real machine debugging

class=”pgc-h-arrow-right” data-track=”39″>

Open the zip package and you will see an Assets directory, which corresponds to the Assets directory of the Unity project. Keep this directory structure in your Unity project.

class=”pgc-h-arrow-right” data-track=”42″>

A complete example is just 3 lines of code:

With xLua installed, create a MonoBehaviour and drag it to the scene. Add the following code to Start:

• • DoString parameter is string, you can enter any legal Lua code, this example calls C# UnityEngine.Debug.Log in lua to print a log
  • A LuaEnv instance corresponds to a Lua virtual machine. For overhead reasons, globally unique

is recommended

XLua.LuaEnv luaenv = new  XLua.LuaEnv();
luaenv.DoString("CS.UnityEngine.Debug.Log('hello world')");
luaenv.Dispose();

C# actively calling lua is also easy. For example, to call lua system functions, the recommended way is:

• declare

[XLua.CSharpCallLua]
public delegate double LuaMax(double a, double b);

• bind

It is recommended to bind once and reuse. If the code is generated, calling max does not produce gc alloc.

var max = luaenv.Global.GetInPath< LuaMax> ("math.max");

• call

Debug.Log("max:" + max(32, 12));

—END—

Open source: BSD-3
